RISER CLAMP
A riser clamp is a type of pipe support device used to secure and support vertical pipes, conduits, or tubing that run along walls, columns, or other structural elements. It is specifically designed to handle the weight of the pipe and any contents it may carry while allowing for thermal expansion, contraction, and movement. Riser clamps are commonly used in various industrial, commercial, and residential applications, such as plumbing, fire protection systems, HVAC (heating, ventilation, and air conditioning), and more.
Riser clamps are available in various sizes and materials, including galvanized steel, stainless steel, and other corrosion-resistant alloys. The choice of material depends on factors such as the environment, the type of pipe being supported, and the specific requirements of the application.
| Pipe Size | Part No. Plain | Part No. Galv. | B | C | Bolt Size |
Max. rec. Load lbs. |
kN |
Wt. Each lbs. |
kg | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2" (50mm) | ASRC50 | ASCHG50 | 10 1/4 | (260.35) | 3 3/4 | (95.25) | 3/8 x 1 1/4 | 300 | (1.33) | 1.20 | (.54) |
| 3" (80mm) | ASRC80 | ASCHG80 | 11 3/4 | (298.45) | 5 1/4 | (133.35) | 3/8 x 1 1/2 | 500 | (2.22) | 1.99 | (.90) |
| 4" (100mm) | ASRC100 | ASCHG100 | 13 | (330.20) | 6 1/2 | (165.10) | 1/2 x 1 3/4 | 750 | (3.34) | 2.21 | (1.00) |
| 6" (150mm) | ASRC150 | ASCHG150 | 15 3/8 | (390.53) | 8 7/8 | (225.43) | 1/2 x 1 3/4 | 1600 | (7.12) | 3.89 | (1.76) |
